Electrical and Interface

--Input voltage: 100-240V~50/60Hz

--Data input/output: 3-pin XLR Socke

--Power connection: PowerCON power input/output

--Power consumption: 650W

light source

--500W LED module light source

--Rated life 20000 hours

--Luminous flux 18500lm

--Color rendering index Ra>80

--Color temperature 7000K

optics

--Advanced optical systems ensure clear imaging quality

--Linear adjustment of light angle from 3 ° to 45 °

colour

--Color: 1 color palette (8 colors+white light) with color flowing rainbow function

pattern

--Pattern: 1 fixed pattern disc (12 patterns+white light), 7 rotating pattern effects

Dimming

--Dimming 0-100% linear adjustment

--Strobe 0-30Hz

Other functions

--1 atomization plate (the atomization plate can be connected to achieve dyeing effect)

--1 prism with 8 prisms and 1 hexagonal prism (capable of independent rotation)

program control

--Control mode DMX512, compatible with RDM,

--Channel mode 22CH/26CH

--Can be upgraded using CX software

move

--X-axis operating angle: 540 ° (16 bit precision scanning)

--Y-axis operating angle: 270 ° (16 bit precision scanning)

--Automatic correction of X/Y axis position out of step

work environment

--Working environment: -0 ℃~55 ℃

--Protection level: IP20

Size and weight

--Lamp size: 380x274x700mm

--Packaging size: 750x360x470mm

--Net weight of product: 23kg

authentication

--CE certification RoSH certification
