Light source

--1Pcs500W LED module light source

--Rated lifespan of light bulb: 20000H

--Color temperature 8500K

--Color rendering index: Ra ≥ 90.

Optical system

--Advanced optical design ensures precise patterns and colors

--Light angle: 3.8 ° -35 ° Linear adjustment

Dimming system

--Dimming: 0-100% linear dimming.

--Aperture: 5%~100% smooth adjustment.

--Strobe: 1-25 times/second ultra high speed strobe effect, can choose from random strobe and pulse strobe.

Control and Program

--Display: LCD display

--Protocol: DMX512, RDM

--Control channel: 23CH/27CH

Move

--X-axis action: 540 °

--Y-axis action: 270 °

--Automatic X/Y position correction

--Accurate scanning with 8 or 16 bits

Colour

--Color disc: 8 colors+1 white light, can rotate rainbow effect in both directions

--CMY: Linear adjustment

--CTO system: 2800K-6500K linearly adjustable

Pattern

--Rotating pattern disc: 7 detachable patterns+white light; Bidirectional adjustable speed rotating pattern chip

Cutting system

--A controllable spot cutting system consisting of 8 corner cutting blades can create any shape of spot through precise control of the cutting blade.

Electrical and connectors

--Input voltage range: 100-240~50/60Hz

--Power consumption: 650W

--Data input/output: 3-pin XLR Socket

Work environment

--Maximum ambient temperature: 55 ° C

--Minimum operating temperature: -0 ° C

--Protection level: IP20

Size and weight

--Size: 390 x W80 x 670mm (L * W * H)

--Net weight: 24kg
