light source

Light source: PHILPS Sllvre300LL

Expected service life of light bulbs: up to 6000 hours

Color temperature 7800K

optical system

Advanced optical design ensures precise patterns and colors

Beam angle: 2 °

Pattern angle: 3 ° -28 °

Control and Program

Display: LCD display

Protocol: DMX512, RDM

Control channel: 20/22CH

move

X-axis action: 540 °

Y-axis action: 270 °

Automatic X/Y position correction

Accurate scanning with 8 or 16 bits

colour

11 color patches+white light (with flowing colors to achieve rainbow effect)

pattern

Static pattern plate: 17 patterns+white light;

Rotating pattern disc: 9 detachable patterns+white light; Bidirectional adjustable speed rotating pattern chip

prism

1 rotatable 8-prism,

Other functions

Electronic zoom and autofocus

Dyeing effect achieved with atomized flakes

Electrical and connectors

Input voltage range: 100-240~50/60Hz

Power consumption: 450W

Data input/output: 3-pin XLR Socket

work environment

Maximum ambient temperature: 55 ° C

Minimum operating temperature: 0 ° C

Waterproof grade: IP20

Size and weight

Size: 525 * 305 * 265mm

Net weight: 14.5kg
