Electrical and connectors

Input voltage range: 100-240~50/60Hz

Power consumption: 1100W (instantaneous power 1500W)

Data input/output: 3-pin XLR Socket

light source

Main light: 1440 0.5w RGB LEDs

Middle: 270 2W WW CW LEDs

Edge: 140 0.5w RGB+100 2w WW CW LEDs

Rated life: 20000H

move

Y-axis shaking head: 270 ° (16 bit precision scanning)

colour

RGB+CW WW color mixing

effect

Built in graphic effects with various color effects

Independent control of 240 main RGB zones.

Independent control of 10 partitions in the middle CW WW

Edge RGB+WW CW20 independent partition control

Software and Control

Operation mode: DMX512/RDM/Art net

Control channel mode: 24CH/26CH/16CH+843CH)

It is possible to purchase jazz software or other third-party software control through Art net other

Advanced and convenient full-color LCD

Can be reversed by 180 ° to adapt to different installation positions

Size and weight

Size: 535 * 265 * 383 * mm

Net weight: 16.9kg

authentication

CE certification RoSH certification
